▒ 특 징
◎ Accepts 200mV AC/DC, 2V AC/DC & 20mA DC input
◎ Instant Graphic/Data Print out
◎ Datalogging for Data Recording, Storing and Analysis(RS-232)
◎ Programmable Unit, Hi-Lo Alarm & Date/Time stamp
◎ Ideal for Laboratory & Process Engineering
◎ Display : 3 1/2 LCD
▒ 사 양
◎ Analog measurement range : 0~200mVAC, 0~200mVDC, 0~2VAC, 0~2VDC,0~20mADC
◎ Accuracy : DC ±(1% rdg + 3 dgts), AC ±(1% rdg + 5 dgts) at 50~450Hz
◎ Resolution : 200mV : 0.1mV , 2V : 1mV , 20mA : 0.01mA
◎ Input protection : 24VDC/AC , 250V/0.5A Fuse (MAX)
◎ Sampling rate(A/D) : 2.5 time/sec
◎ Operating/Storage temp. & humidity : 0~40℃(32~104℉) & 10~80%RH
-10~60℃(14~140℉) & 10~70%RH
◎ Power supply : 6 pcs 1.5V AA Batteries
110V/220VAC to 9V DC Power adapter
◎ Battery life : 100hrs(without printing)
◎ Dimensions & Weight : 250(L)×100(W)×45(H)mm, 500g including batteries
◎ Memory : 60,000 records
◎ Accessories : Thermo Carrying Case, Test leads with Alligator clip,
2 rolls of Thermo Paper, Instruction Manual,
110V/220V AC to 9V DC Power adapter/Power Cord,
RS-232 Cable, PC Software disk, 6 pcs 1.5V AA Batteries,
TL-A37 analog Recording Cable
|
