▒ 특 징
STOCKED MODELS in bold Model | Range | Metric Range | Maximum Pressure | 477-1- FM | 0 ~ 20 in. w.c | 0 ~ 5 kPa | 11 psi ( 0.75 bar ) | 477-2- FM | 0 ~ 40 in. w.c | 0 ~ 10 kPa | 11 psi ( 0.75 bar ) | 477-3- FM | 0 ~ 200 in. w.c | 0 ~ 50 kPa | 29 psi ( 1.99 bar ) | 477-4- FM | 0 ~ 10 psid | 0 ~ 70 kPa | 58 psi ( 3.99 bar ) | 477-5- FM | 0 ~ 30 psid | 0 ~ 200 kPa | 58 psi ( 3.99 bar ) | 477-6- FM | 0 ~ 100 psid | 0 ~ 700 kPa | 150 psi ( 103 bar ) | 477-7- FM | 0 ~ 150 psid | 0 ~ 1000 kPa | 200 psi ( 13.7 bar ) |
Specifications Accuracy : ± 0.5 % full scale
Temperature Limits : -20 ~ 80 ℃
Pressure Connections : Barbed . for 1/8 or 3/16 I.D tubing
Power Source : 9V battery
Pressure Display : 0.4 liquid crystal
Size : 166 x 71 x 23 mm
Weight : 340g PRESSURE UNITS AVAILABLE Model | PSID | in H2O | mmH2O | in Hg | mm Hg | Pa | kPa | bar | mbar | 477-1-FM | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | 477-2-FM | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | 477-3-FM | ▲ | ▲ | ▲ | ▲ | ▲ | | ▲ | ▲ | ▲ | 477-4-FM | ▲ | ▲ | ▲ | ▲ | ▲ | | ▲ | ▲ | ▲ | 477-5-FM | ▲ | ▲ | | ▲ | ▲ | | ▲ | ▲ | ▲ | 477-6-FM | ▲ | ▲ | | ▲ | ▲ | | ▲ | ▲ | ▲ | 477-7-FM | ▲ | ▲ | | ▲ | ▲ | | ▲ | ▲ | ▲ |
|
